Hose connector for art. 227, 247, 248

Ref. 249
Conditions of use
• Suitable for applications subject to vibrations or humid environments (condensation).
• Pressure measuring : Ranges from -1 to 1000 bar.
• Overpressures : The maximum pressure under static load must not exceed 75% of the maximum value of the measurement range, or 65% under dynamic load. This will increase the life of the device.
• Temperature : -40°C / +65°C.

Technical features
• Brass mechanism with copper Bourdon tube.
• Product designed, manufactured and controlled according to EN 837-1 standard (Bourdon tube pressure gauges).
• 100% inspection with 5 measuring points.
• Accuracy class 1.6 (±1.6% of the measuring range).
• Silicon filled stainless steel 304 cases.
• Radial brass connection with BSPP Mâle thread (ISO 228-1).
• Dial with double graduation bar/psi.

Individual box for distribution.
ILV See the POS marketing kit ADVANCE
  • 4MS
Change connector type
See all configurations
Ø Code SU Box Pallet Stock Qty
1/2" 29491 10 10 480
3/4" 29492 10 10 100
1" 29493 10 10 100
1"1/4 29494 10 10 100
Créer
Hose connector for art. 227, 247, 248
Ø ØB RÉF. 227 / 248 / 247 ØT
1/2" 1/2" 12/13
3/4" 3/4" 15
1" 1" 19/20
1"1/4 1"1/4 25
(mm)
